PCS250
GPRS/GSM Communicator Module
PCS250
Available
GPRS/GSM Communicator Module
- Compact, sleek design
- Report events to the IPR512 GPRS/IP Monitoring Receiver and/or IPRS-7 IP/GPRS PC Receiver Software
- Report via text message (up to 16 cell phone numbers)
- Control panel communication supervision
- End-user can arm or disarm the system by sending a text message (SMS) to the PCS250
- Send pre-recorded voice messages to up to 8 telephone numbers to report alarms using the optional VDMP3 Paradox Plug-in Voice Module (GSM mode)
- Simple installation with 4-wire serial connection
- Optional rod antenna can be installed up to 18m (60ft) from the module using optional antenna cable extensions depending on the local signal strength
- 128-bit (MDS) and 256-bit (AES) encryption (GPRS mode)
- Increase the distance between the panel and the PCS250 module with an RS485 link (GSM mode only via e-bus). A CVT485 module must be added to the panel in order to accomplish this
- Report via GSM (CID, SIA)
- Compatibility
- EVO48 and EVO192 panels V2.02
- K641 and K641R keypads V1.51 or higher
- SP series V3.42 with K32LCD keypads V1.22
- E55 panels V3.0 (labels to be programmed via Winload)
- E65 panels V2.1 (labels to be programmed via Winload)
- MG series V4.0 or higher with K32LCD keypads V1.22 or higher
